15 / 32 page

Data Sheet

ADL5243

Rev. A | Page 15 of 32

–40

–35

–30

–25

–20

–15

–10

–5

0.1

4.1

3.7

3.3

2.9

2.5

2.1

1.7

1.3

0.9

0.5

FREQUENCY (GHz)

31.5dB

0dB

Figure 27. DSA: Attenuation vs. Frequency

–36

–31

–26

–21

–16

–11

–6

–1

0.1

4.1

3.7

3.3

2.9

2.5

2.1

1.7

1.3

0.9

0.5

FREQUENCY (GHz)

0dB

4dB

8dB

16dB

31.5dB

–40°C

+25°C

+85°C

Figure 28. DSA: Attenuation vs. Frequency and Temperature

–0.5

–0.4

–0.3

–0.2

–0.1

0.1

0.2

0.3

0.4

0.5

032

ATTENUATION (dB)

450MHz

748MHz

943MHz

1960MHz

2140MHz

2630MHz

3600MHz

Figure 29. DSA: Step Error vs. Attenuation

–1.0

–0.8

–0.6

–0.4

–0.2

0.2

0.4

0.6

0.8

1.0

ATTENUATION (dB)

450MHz

748MHz

943MHz

1960MHz

2140MHz

2630MHz

3600MHz

Figure 30. DSA: Absolute Error vs. Attenuation

–30

–25

–20

–15

–10

–5

0.1

4.1

3.7

3.3

2.9

2.5

2.1

1.7

1.3

0.9

0.5

FREQUENCY (GHz)

31.5dB

0dB

Figure 31. DSA: Input Return Loss vs. Frequency, All States

–30

–25

–20

–15

–10

–5

0.1

4.1

3.7

3.3

2.9

2.5

2.1

1.7

1.3

0.9

0.5

FREQUENCY (GHz)

31.5dB

0dB

Figure 32. DSA: Output Return Loss vs. Frequency, All States
