6 | Safety Light Curtain F3SG-R Series

Visualization eliminates machine downtime

Stable operation and predictive maintenance

The lamp notifies low light

intensity

The lamp notifies when the incident light level drops due to

dirt, which prevents sudden stops.

Bluetooth® allows to check status

without stopping the line

Data logging for quick

troubleshooting

The error logs stored in the F3SG-RA can be downloaded

to a PC that is connected with the F3SG-RA using the

dedicated interface unit. The Configuration Tool SD

Manager2 can be used to analyze errors to identify causes

and solutions. The data on light intensity, power-ON time,

and switching frequency can also be collected regularly for

predictive maintenance.

The SD Manager2 can be used to check the status of the safety light curtain

wirelessly after pairing the safety light curtain with PC via Bluetooth®, which

reduces maintenance time.

Wireless connectivity

- Monitoring during operation

- No possibility of blocking beams

- No work required after completing checks

- Monitoring from anywhere

- Serial number to choose the right safety light

curtain from many installed on lines

F39-LP Lamp

* The incident light level at which the

light curtain turns OFF

Configuration Tool SD Manager2

Line A

Line B

The lamp notifies when

the light intensity drops

near the threshold*

At a glance

warning

F39-BT/BTLP Bluetooth®

Communication Unit

F3SG-

Multifunctional

Advanced

type

e lamp notifies low light

ensity

mp notifies when the incident light level drops due to

hich prevents sudden stops.

uetooth® allows to check status

thout stopping the line

Data logging for quick

troubleshooting

The error logs stored in the F3SG-RA can be downloaded

to a PC that is connected with the F3SG-RA using the

dedicated interface unit. The Configuration Tool SD

Manager2 can be used to analyze errors to identify causes

and solutions. The data on light intensity, power-ON time,

and switching frequency can also be collected regularly for

predictive maintenance.

D Manager2 can be used to check the status of the safety light curtain

essly after pairing the safety light curtain with PC via Bluetooth®, which

es maintenance time.

Wireless connectivity

Monitoring during operation

No possibility of blocking beams

No work required after completing checks

Monitoring from anywhere

Serial number to choose the right safety light

curtain from many installed on lines

F39-LP Lamp

incident light level at which the

t curtain turns OFF

Configuration Tool SD Manager2

Line A

Line B

The lamp notifies when

the light intensity drops

near the threshold*

At a glance

warning

F39-BT/BTLP Bluetooth®

Communication Unit

Time
