F3SG-R datasheet(100/164 Pages) OMRON

100 / 164 page

F3SG-RA-01TS

100

Bluetooth Communication Unit

* It depends on use environment conditions.

Environ-

mental

Ambient Temperature

Operating

-10 to 55°C (14 to 131°F) (non-icing)

Storage

-25 to 70°C (-13 to 158°F)

Ambient Humidity

Operating

35% to 85% (non-condensing)

Storage

35% to 95%

Ambient Illuminance

Incandescent lamp: 3,000 Ix max. on receiver surface

Sunlight: 10,000 Ix max. on receiver surface

Degree of Protection

(IEC 60529)

IP65 and IP67

Vibration Resistance

(IEC 61496-1)

10 to 55 Hz, Multiple amplitude of 0.7 mm, 20 sweeps for all 3 axes

Shock Resistance

(IEC 61496-1)

100 m/s2, 1000 shocks for all 3 axes

Pollution Degree

(IEC 60664-1)

Pollution Degree 3

Connec-

tions

Power cable

Type of Connection

M12 connectors: 8-pin emitter and receiver, IP67 rated when mated,

Cables pre-wired to the sensors

Number of Wires

On emitter: 5-wire, On receiver: 8-wire

Cable Length

0.3 m

Cable Diameter

6 mm

Minimum Bending

Radius

R5 mm

Cascading cable

Type of Connection

M12 connectors: 8-pin emitter and receiver, IP67 rated when mated

Number of Wires

On emitter: 5-wire, On receiver: 8-wire

Cable Length

0.2 m

Cable Diameter

6 mm

Minimum Bending

Radius

R5 mm

Extension cable

- Single-Ended Cable

- Double-Ended Cable

Type of Connection

M12 connectors: 8-pin emitter and receiver, IP67 rated when mated

Number of Wires

On emitter and receiver: 8-wire

Cable Length

Refer to page 94.

Cable Diameter

6.6 mm

Minimum Bending

Radius

R36 mm

Extension of Power Cable

100 m max.(Emitter/Receiver)

Material

Housing: Aluminum alloy

Cap: PBT resin

Front window: Acrylic resin

Cable: Oil-resistant PVC resin

FE plate: Stainless steel

Weight

Refer to page 101 .

Included Accessories

Safety Precautions, Quick Installation Manual, Troubleshooting Guide Sticker,

Conformity

Conforming standards

Refer to page 102 .

Type of ESPE (IEC 61496-1)

Type 4

Performance Level (PL)/

Safety category

PL e/Category 4 (EN ISO 13849-1:2015)

PFHD

1.1 × 10-8 (IEC 61508)

Proof test interval TM

Every 20 years (IEC 61508)

SFF

99% (IEC 61508)

HFT

1 (IEC 61508)

Classification

Type B (IEC 61508-2)

Communication System

Bluetooth Version 3.0

Communication Profile

SPP (Serial Port Profile)

Transmission Distance

Approx. 10 m max. (Output power: Class 2) *

F3SG-4RA-25-01TS
