F3SG-RE
80
LED Indicator Status
Emitter
Receiver
Name of Indicator
Color
Illuminated
Blinking
Operating range
LONG
Green
Long range mode is selected
Lockout state due to Operating range selection setting error
Power
POWER
Green
Power is ON.
Error due to noise
Lockout
LOCKOUT
Red
−
Lockout state due to error in emitter
Name of Indicator
Color
Illuminated
Blinking
Top-beam-state
TOP
Blue
The top beam is unblocked
−
Internal error
INTERNAL
Red
−
Lockout state due to Internal error, or error due to abnormal
power supply or noise
Lockout
LOCKOUT
Red
−
Lockout state due to error in receiver
Stable-state
STB
Green
Incident light level is 170% or higher of ON threshold
Safety output is instantaneously turned OFF due to ambi-
ent light or vibration
ON/OFF
ON/OFF
Green
Safety output is in ON state
−
Red
Safety output is in OFF state
Lockout state due to Safety Output error, or error due to ab-
normal power supply or noise
Communication
COM
Green
Synchronization between emitter and receiver is main-
tained
Lockout state due to Communication error, or error due to
abnormal power supply or noise
Bottom-beam-state
BTM
Blue
The bottom beam is unblocked
−
