Safety Light Curtain Easy type

F3SG-RE

Easy-to-use Safety Sensor Ideal for

Simple On/Off Detection Applications

• Provides simple safety functions - saving TCO

by reducing errors

• Simple wiring with only 4 wires

• Fast response time of 5 ms

System Configuration

F39-HGB

@@@@

Spatter Protection Cover

(for F3SG-RE)

F39-PTG

Laser Pointer

Accessory

Emitter

Receiver

XS5W-D421-

@81-F

Double-Ended Cable

XS5F-D421-

@80-F

Single-Ended Cable

F39-LGF

Standard Fixed Bracket

(included as standard)

F39-LGA

Standard Adjustable

Bracket

F39-LGTB

F39-LGTB-1

Top/Bottom Adjustable

Bracket

Mounting bracket

F39-GCNY1

XS5W-D421-

@81-F

XS5F-D421-

@80-F

Reduced wiring connector system

NX/NE1A-series

Safety Network Controller

G9SP-series

Safety Controller

G9SE/G9SA-series

Safety Relay Unit

G9SX-series

Flexible Safety Unit

G7SA/G7S-E

Relays with Forcibly

Guided Contacts

Recommended safety controller *

* The recommended safety controller is required to

build a safety circuit using emergency stop

switches and door switches.

Accessory

F39-GCNY1

XS5W-D421-

@81-F

XS5F-D421-

@80-F
