F3SG-R Arkusz danych(PDF) 24 Page - Omron Electronics LLC |
|
|
|||||||||||||||||||||||||||||
F3SG-R Arkusz danych(HTML) 24 Page - Omron Electronics LLC |
|
|
24 / 164 page  F3SG-RA 24 Bluetooth Communication Unit * It depends on use environment conditions. Environ- mental Ambient Temperature Operating -10 to 55°C (14 to 131°F) (non-icing) Storage -25 to 70°C (-13 to 158°F) Ambient Humidity Operating 35% to 85% (non-condensing) Storage 35% to 95% Ambient Illuminance Incandescent lamp: 3,000 Ix max. on receiver surface Sunlight: 10,000 Ix max. on receiver surface Degree of Protection (IEC 60529) IP65 and IP67 Vibration Resistance (IEC 61496-1) 10 to 55 Hz, Multiple amplitude of 0.7 mm, 20 sweeps for all 3 axes Shock Resistance (IEC 61496-1) 100 m/s2, 1000 shocks for all 3 axes Pollution Degree (IEC 60664-1) Pollution Degree 3 Connec- tions Power cable Type of Connection M12 connectors: 5-pin emitter and 8-pin receiver, IP67 rated when mated, Cables prewired to the sensors Number of Wires Emitter: 5, Receiver: 8 Cable Length 0.3 m Cable Diameter 6 mm Minimum Bending Radius R5 mm Cascading cable Type of Connection M12 connectors: 5-pin emitter and 8-pin receiver, IP67 rated when mated Number of Wires Emitter: 5, Receiver: 8 Cable Length 0.2 m Cable Diameter 6 mm Minimum Bending Radius R5 mm Extension cable - Single-Ended Cable - Double-Ended Cable Type of Connection M12 connectors: 5-pin emitter and 8-pin receiver, IP67 rated when mated Number of Wires Emitter: 5, Receiver: 8 Cable Length Refer to page 18. Cable Diameter 6.6 mm Minimum Bending Radius R36 mm Extension of Power Cable 100 m max. Material Material Housing: Aluminum alloy Cap: PBT resin Front window: Acrylic resin Cable: Oil-resistant PVC resin Standard Fixed Bracket (F39-LGF): Zinc alloy FE plate: Stainless steel Weight Refer to page 25. Included Accessories Safety Precautions, Quick Installation Manual, Standard Fixed Bracket *, Troubleshooting Guide Sticker, Warning Zone Label *The quantity of Standard Fixed Brackets included varies depending on the protective height. [F3SG- RA-14] - Protective height of 0160 to 1200: 2 sets - Protective height of 1280 to 2080: 3 sets [F3SG- RA-30] - Protective height of 0190 to 1230: 2 sets - Protective height of 1310 to 2270: 3 sets - Protective height of 2350 to 2510: 4 sets Conformity Conforming standards Refer to page 26. Type of ESPE (IEC 61496-1) Type 4 Performance Level (PL)/Safety category Type 4 PL e/Category 4 (EN ISO 13849-1:2015) Type 2 PL c/Category 2 (EN ISO 13849-1:2015) PFHD 1.1 × 10-8 (IEC 61508) Proof test interval TM Every 20 years (IEC 61508) SFF 99% (IEC 61508) HFT 1 (IEC 61508) Classification Type B (IEC 61508-2) Communication System Bluetooth Version 3.0 Communication Profile SPP (Serial Port Profile) Transmission Distance Approx. 10 m max. (Output power: Class 2) * F3SG-4RA-14 F3SG-2RA-14 F3SG-4RA-30 F3SG-2RA-30 |
|
