F3SG-R datasheet(85/164 Pages) OMRON

85 / 164 page

F3SG-RE

Dimensions

(Unit: mm)

Mounted with Standard Fixed Brackets (F39-LGF)

Backside Mounting

*1.The number of brackets required to mount either one of emitter and receiver.

*2.Mounting an emitter or receiver with one bracket is possible for the models of protective height of 0160 to 0270. In this case, locate this bracket at half the Dimension

A (or at the center of the sensor length).

F3SG-4RE

@@@@@30 Series

Dimension A

Dimension C1

4-digit number of the type name(Protective height)

Dimension D

C1-50

Dimension P

Protective height

(C1)

Number of Standard

Fixed Brackets *1

Dimension F

0190 to 1230

2 *2

1000 mm max.

1310 to 2270

1000 mm max.

2350 to 2510

1000 mm max.

F3SG-4RE

@@@@@14 Series

Dimension A

C2+30

Dimension C2

4-digit number of the type name(Protective height)

Dimension D

C2-20

Dimension P

Protective height

(C2)

Number of Standard

Fixed Brackets *1

Dimension F

0160 to 1200

2 *2

1000 mm max.

1280 to 2080

1000 mm max.

24.85

9.2

2-M5 or M6

Standard Fixed

Bracket

Standard Fixed

Bracket

(F39-LGF)

< Screw: M5 or M6 >
