F3SG-RA

Legislation and Standards

1. The F3SG-R does not receive type approval provided by Article 44-2 of the Industrial Safety and Health Act of Japan. When using the F3SG-R

in Japan as a "safety system for pressing or shearing machines" prescribed in Article 42 of that law, the machine control system must receive

type approval.

2. The F3SG-R is electro-sensitive protective equipment (ESPE) in accordance with European Union (EU) Machinery Directive Index Annex V,

Item 2.

3. EC Declaration of Conformity

OMRON declares that the F3SG-R is in conformity with the requirements of the following EC Directives:

Machinery Directive 2006/42/EC

EMC Directive2014/30/EU

4. Conforming Standards

(1) European standards

EN61496-1 (Type 4 and Type 2 ESPE), EN 61496-2 (Type 4 and Type 2 AOPD), EN61508-1 through -4 (SIL 3 for Type 4 and SIL 1 for

Type 2), EN ISO 13849-1:2015 (PL e, Category 4 for Type 4 and PL c, Category 2 for Type 2)

(2) International standards

IEC61496-1 (Type 4 and Type 2 ESPE), IEC61496-2 (Type 4 and Type 2 AOPD), IEC61508-1 through -4 (SIL 3 for Type 4 and SIL 1 for

Type 2), ISO 13849-1:2015 (PL e, Category 4 for Type 4 and PL c, Category 2 for Type 2)

(3) JIS standards

JIS B 9704-1 (Type 4 and Type 2 ESPE), JIS B 9704-2 (Type 4 and Type 2 AOPD)

(4) North American standards

UL61496-1(Type 4 and Type 2 ESPE), UL61496-2(Type 4 and Type 2 AOPD), UL508, UL1998,

CAN/CSA C22.2 No.14, CAN/CSA C22.2 No.0.8

(5) Chinese standards

GB/T 4584(Specification of active opto-electronic protective devices for presses)

5. Third-Party Certifications

(1) TÜV SÜD

• EC Type-Examination certificate:

EU Machinery Directive, Type 4 and Type 2 ESPE (EN61496-1), Type 4 and Type 2 AOPD (EN 61496-2)

• Certificate:

Type 4 and Type 2 ESPE (EN61496-1), Type 4 and Type 2 AOPD (EN61496-2), EN 61508-1 through -4 (SIL 3 for Type 4 and SIL 1 for

Type 2), EN ISO 13849-1:2015 (PL e, Category 4 for Type 4, and PL c, Category 2 for Type 2)

(2) UL

• UL Listing:

Type 4 and Type 2 ESPE (UL61496-1), Type 4 and Type 2 AOPD (UL61496-2), UL508, UL1998, CAN/CSA C22.2 No.14, CAN/CSA C22.2

No.0.8

(3) China National Casting and Forging Machines Quality Supervision and Inspection Center

• Certificate:

GB/T 4584 (Specification of active opto-electronic protective devices for presses)

6. Other Standards

The F3SG-R is designed according to the standards listed below. To make sure that the final system complies with the following standards and

regulations, you are asked to design and use it in accordance with all other related standards, laws, and regulations. If you have any questions,

consult with specialized organizations such as the body responsible for prescribing and/or enforcing machinery safety regulations in the location

where the equipment is to be used.

• European Standards: EN415-4, EN691-1, EN692, EN693, IEC 62046

• U.S. Occupational Safety and Health Standards: OSHA 29 CFR 1910.212

• U.S. Occupational Safety and Health Standards: OSHA 29 CFR 1910.217

• American National Standards: ANSI B11.1 to B11.19

• American National Standards: ANSI/RIA R15.06

• Canadian Standards Association CSA Z142, Z432, Z434

• SEMI Standards SEMI S2

• Japan Ministry of Health, Labour and Welfare "Guidelines for Comprehensive Safety Standards of Machinery", Standard Bureau's Notification

No. 0731001 dated July 31, 2007.rms and Conditions Agreement

• Chinese National Standards: GB17120, GB27607
