F3SG-RR

Accessories (Sold separately)

Safety light curtain connecting cable

Single-Ended Cable (Oil-Resistant Cable)

Note: To extend the cable length to more than 7 m, add the F39-JD

@B Double-Ended Cable.

When the Double-Ended Cable is used, protect it from cutting oil.

Single-Ended Cable (2 cables per set, one for emitter and one for receiver) *

* The cable for emitter and the cable for receiver are available separately. Add '-L' for emitter or '-D' for receiver to the end of the model number

when you order.

Single-Ended Cable for Emitter: F39-JD

@A-L, Single-Ended Cable for Receiver: F39-JD@A-D

Note: 1. Use the F39-JD

@RA-L/-D for applications where cutting oil resistance is required.

2. To extend the cable length to more than 20 m, add the F39-JD

@B Double-Ended Cable.

Appearance

Type

Cable length

Specifications

Model

For emitter

M12 connector

(8-pin), 5 wires

Color: Gray

3 m

F39-JD3RA-L

7 m

F39-JD7RA-L

For receiver

M12 connector

(8-pin), 8 wires

Color: Black

3 m

F39-JD3RA-D

7 m

F39-JD7RA-D

Appearance

Cable length

Specifications

Model

3 m

F39-JD3A

7 m

F39-JD7A

10 m

F39-JD10A

15 m

F39-JD15A

20 m

F39-JD20A

Female

+24 VDC

0 VDC

Not used

Connected to Power Cable or Double-Ended Cable

Brown

Blue

Gray

Pink

−

8Not used

−

3TEST

Black

Not used

−

Female

+24 VDC

0 VDC

MUTE A /PC COM (+)

MUTE B /PC COM (-)

OSSD 2

Connected to Power Cable or Double-Ended Cable

Brown

Blue

Gray

Pink

White

RESET/EDM

Red

OSSD 1

Black

4AUX

Yellow

For emitter, M12 connector (8-pin), Color: Gray

For receiver, M12 connector (8-pin), Color: Black

IP67 and IP67G (JIS C 0920 Annex 1)* rated when mated.

* F3SG-RR meets the degree of protection when this cable

is correctly connected with the power cable of the F3SG-

RR. The degree of protection is not satisfied with the part

where cable wires are uncovered.

Female

+24 VDC

0 VDC

Not used

Connected to Power Cable or Double-Ended Cable

Brown

Blue

Gray

Pink

White

8Not used

Red

3TEST

Black

Not used

Yellow

Shield

Female

+24 VDC

0 VDC

MUTE A /PC COM (+)

MUTE B /PC COM (-)

OSSD 2

Connected to Power Cable or Double-Ended Cable

Brown

Blue

Gray

Pink

White

RESET/EDM

Red

OSSD 1

Black

4AUX

Yellow

Shield

For emitter M12 connector (8-pin), Color: Gray

For receiver M12 connector (8-pin), Color: Black

IP67* rated when mated.

* When the accessory is used, protect it from cutting oil.
