4 / 164 page  4 | Safety Light Curtain F3SG-R Series Simple beam adjustment Simply watch for the top and bottom indicators to illuminate when adjustment is completed. The optional laser pointer and lamp can be used to reduce the time required to set up the light curtain. TOP (top-beam-state indicator) BTM (bottom-beam-state indicator) F39-PTG Laser Pointer Shows the sensor direction Turns ON when safety output turns ON, making adjustment easier F39-LP Lamp The incident light levels of each beam can be checked with the Configuration Tool SD Manager2 Sufficient Green Insufficient Red Fine beam adjustment Sh Sh Tu ou ma ea F39-LP Lamp Intuitive and smart designs for fast set-up Quick and easy installation Also The TOP indicator turns ON when the top beam is unblocked 1 The BTM indicator turns ON when the bottom beam is unblocked 2 Mounting brackets Four types of mounting brackets provide vertical or vertical and horizontal adjustment even after mounting, making beam adjustment easier. Standard fixed bracket You can slide the F3SG-R up and down to make vertical adjustments after mounting on a safety fence. Standard adjustable bracket (sold separately) This bracket provides vertical as well as horizontal adjustment of ±15º. Top/bottom adjustable bracket (sold separately) Use this bracket at the top and bottom of the F3SG-R to make horizontal adjustment of ±22.5º. Top/bottom adjustable bracket (for user-made mounting part) (sold separately) The wall mounting bracket is not provided so that you can design your own wall mounting part. r p R p R k o l ket ou l ±15° ±22.5° F3SG- RA Multifunctional Advanced type * Image for illustration purpose only. |
|
