F3SG-RE

Perfor-

mance

Light Source

Infrared LEDs, Wavelength: 870 nm

Startup Waiting Time

2 s max.

Electricall

Power Supply Voltage (Vs)

SELV/PELV 24 VDC

±20% (ripple p-p 10% max.)

Current Consumption

Refer to page 79

Safety Outputs (OSSD)

F3SG-

@RE@@@@P@@: Two PNP transistor outputs

F3SG-

@RE@@@@N@@: Two NPN transistor outputs

Load current of 300 mA max., Residual voltage of 2 V max. (except for voltage drop due to cable

extension), Capacitive load of 1

μF max., Inductive load of 2.2 H max. *1

Leakage current of 1 mA max. (PNP), 2 mA max. (NPN) *2

*1.The load inductance is the maximum value when the safety output frequently repeats ON and OFF.

When you use the safety output at 4 Hz or less, the usable load inductance becomes larger.

*2.These values must be taken into consideration when connecting elements including a capacitive

load such as a capacitor.

Output Operation

Mode

Safety

Output

Light-ON (Safety output is enabled when the receiver receives an emitting signal.)

Input Voltage

ON Voltage

Operating Range Select Input:

Long: 9 V to Vs (sink current 3 mA max.) *

Short: 0 to 3 V (source current 3 mA max.)

OFF Voltage

*The Vs indicates a supply voltage value in your environment.

Overvoltage Category (IEC60664-1) II

Indicators

Refer to page 80

Protective Circuit

Output short protection, Power supply reverse polarity protection

Insulation Resistance

20 M

Ω or higher (500 VDC megger)

Dielectric Strength

1,000 VAC, 50/60 Hz (1 min)

Functional Test Function

Self-test (at power-on, and during operation)

Environ-

mental

Ambient

Temperature

Operating

-10 to 55

°C (14 to 131°F) (non-icing)

Storage

-25 to 70

°C (-13 to 158°F)

Ambient

Humidity

Operating

35% to 85% (non-condensing)

Storage

35% to 95%

Ambient Illuminance

Incandescent lamp: 3,000 Ix max. on receiver surface

Sunlight: 10,000 Ix max. on receiver surface

Degree of Protection (IEC 60529)

IP65 and IP67

Vibration Resistance (IEC 61496-1)

10 to 55 Hz, Multiple amplitude of 0.7 mm, 20 sweeps for all 3 axes

Shock Resistance (IEC 61496-1) 100 m/s2, 1000 shocks for all 3 axes

Pollution Degree (IEC 60664-1)

Pollution Degree 3

Connec-

tions

Power cable

Type of Connection M12 connectors: 4-pin, IP67 rated when mated,Cables prewired to the sensors

Number of Wires

Emitter: 4, Receiver: 4

Cable Length

0.3 m

Cable Diameter

6 mm

Minimum Bend-

ing Radius

R5 mm

Extension cable

- Single-Ended

Cable

- Double-Ended

Cable

Type of Connection

Use the XS5

@-D42@ series cables.

Number of Wires

Cable Length

Cable Diameter

Minimum Bend-

ing Radius

Extension of Power Cable

100 m max.

Material

Housing: Aluminum alloy

Cap: PBT resin

Front window: Acrylic resin

Cable: Oil-resistant PVC resin

Standard Fixed Bracket (F39-LGF): Zinc alloy

FE plate: Stainless steel

Weight

Refer to page 79.

Included Accessories

Safety Precautions, Quick Installation Manual, Standard Fixed Bracket*1, Troubleshooting Guide

Sticker

*1.The quantity of Standard Fixed Brackets included varies depending on the protective height.

[F3SG-

@RE@@@@@14]

- Protective height of 0160 to 1200: 2 sets

- Protective height of 1280 to 2080: 3 sets

[F3SG-

@RE@@@@@30]

- Protective height of 0190 to 1230: 2 sets

- Protective height of 1310 to 2270: 3 sets

- Protective height of 2350 to 2510: 4 sets

Conformity

Conforming standards

Refer to page 26

Performance Level

(PL)/Safety category

Type 4

PL e/Category 4 (EN ISO 13849-1:2015)

Type 2

PL c/Category 2 (EN ISO 13849-1:2015)

PFHD

9.1

× 10-9 (IEC 61508)

Proof test interval TM

Every 20 years (IEC 61508)

SFF

99% (IEC 61508)

HFT

1 (IEC 61508)

Classification

Type B (IEC 61508-2)

F3SG-4RE

@@@@-14, F3SG-2RE@@@@-14

F3SG-4RE

@@@@-30, F3SG-2RE@@@@-30
