50 / 164 page ![]() F3SG-RR 50 Ratings and Specifications Main unit The @@@@ in the model names indicate the protective heights in millimeters. F3SG-4RR-14 F3SG-4RR-25 Performance Object Resolution (Detection Capability) Opaque objects 14-mm dia. 25-mm dia. Beam Gap 10 mm 20 mm Number of Beams 23 to 191 12 to 96 Lens Size 5.2 × 3.4 (W × H) mm 6.0 × 5.0 (W × H) mm Protective Height 240 to 1920 mm Operating Range 0.3 to 10.0 m 0.3 to 17.0 m Response Time ON to OFF Normal mode: 8 to 18 ms *1 Slow mode: 16 to 36 ms *1 *2 OFF to ON Normal mode: 40 to 90ms (synchronized), 140 to 190ms (not synchronized) *1 *1. Response time when used in one segment system or in cascaded connection. Refer to page 52. *2. Selectable by Configuration Tool. Effective Aperture Angle (EAA) (IEC 61496-2) ±2.5° max., emitter and receiver at operating range of 3 m or greater Light Source Infrared LEDs, Wavelength: 870 nm Startup Waiting Time 2 s max. Electrical Power Supply Voltage (Vs) SELV/PELV 24 VDC±20% (ripple p-p 10% max.) Current Consumption Refer to page 52 . Safety Outputs (OSSD) Two PNP or NPN transistor outputs (PNP or NPN is selectable by Configuration Tool.) Load current of 300 mA max., Residual voltage of 2 V max. (except for voltage drop due to cable extension), Capacitive load of 1 μF max., Inductive load of 2.2 H max. *1 Leakage current of 1 mA max. (PNP), 2 mA max. (NPN) *2 *1. The load inductance is the maximum value when the safety output frequently repeats ON and OFF. When you use the safety output at 4 Hz or less, the usable load inductance becomes larger. *2. These values must be taken into consideration when connecting elements including a capacitive load such as a capacitor. Auxiliary Output One PNP or NPN transistor output (PNP or NPN is selectable by Configuration Tool.) Load current of 100 mA max., Residual voltage of 2 V max . Output Operation Mode Safety Output Light-ON (Safety output is enabled when the receiver receives an emitting signal.) Auxiliary Output Safety output (Inverted signal output:Enable) (default) (Cofigurable by Configuration Tool) Input Voltage External device monitoring input (Lockout reset input) PNP ON voltage: Vs-3 V to Vs (short circuit current: approx. 6.5 mA) * OFF voltage: 0 V to 1/2 Vs, or open (short circuit current: approx. 8.0 mA) * NPN ON voltage: 0 V to 3 V (short circuit current: approx. 8.0 mA) OFF voltage: 1/2 Vs to Vs, or open (short circuit current: approx. 6.5 mA) * Muting input A/B PNP ON voltage: Vs-3 V to Vs (short circuit current: approx. 3.0 mA) * OFF voltage: 0 V to 1/2 Vs, or open (short circuit current: approx. 5.0 mA) * NPN ON voltage: 0 V to 3 V (short circuit current: approx. 5.0 mA) OFF voltage: 1/2 Vs to Vs, or open (short circuit current: approx. 3.0 mA) * Test input 24 V Active setting: ON voltage: 9 V to Vs (short circuit current: approx. 2.5 mA) * OFF voltage: 0 V to 1.5 V or open (short circuit current: approx. 2.0 mA) 0 V Active setting: ON voltage: 0 V to 3 V (short circuit current: approx. 2.0 mA) OFF voltage: 9 V to Vs or open (short circuit current: approx. 2.5 mA) * * The Vs indicates a supply voltage value in your environment. Overvoltage Category (IEC 60664-1) II Indicators Refer to page 54. Protective Circuit Output short protection, Power supply reverse polarity protection Insulation Resistance 20 M Ω or higher (500 VDC megger) Dielectric Strength 1,000 VAC, 50/60 Hz (1 min) Functional Mutual Interference Prevention (Scan Code) This function prevents mutual interference in up to two F3SG-RR systems. Cascade Connection Number of cascaded segments: 3 max. Total number of beams: 255 max. Cable length between sensors: 10 m max. (not including cascading cable (F39-JGR2WTS) and power cable) Test Function Self-test (at power-on, and during operation) External test (light emission stop function by test input) Safety-Related Functions Interlock External device monitoring (EDM) Pre-reset Fixed blanking/Floating blanking Reduced resolution Muting/Override Scan code selection PNP/NPN selection Response time adjustment |
|
