51 / 164 page  F3SG-RR 51 Bluetooth Communication Unit * It depends on use environment conditions. Environ- mental Ambient Temperature Operating -10 to 55°C (14 to 131°F) (non-icing) Storage -25 to 70°C (-13 to 158°F) Ambient Humidity Operating 35% to 85% (non-condensing) Storage 35% to 95% Ambient Illuminance Incandescent lamp: 3,000 Ix max. on receiver surface Sunlight: 10,000 Ix max. on receiver surface Degree of Protection (IEC 60529) IEC 60529: IP65 and IP67, JIS C 0920 Annex 1: IP67G Vibration Resistance (IEC 61496-1) 10 to 55 Hz, Multiple amplitude of 0.7 mm, 20 sweeps for all 3 axes Shock Resistance (IEC 61496-1) 100 m/s2, 1000 shocks for all 3 axes Pollution Degree (IEC 60664-1) Pollution Degree 3 Connec- tions Power cable Type of Connection M12 connectors: 8-pin emitter and receiver. Cables prewired to the sensors. IP67 and IP67G (JIS C 0920 Annex 1) * rated when mated. *F3SG-RR meets the degree of protection when it is correctly connected with an F39-JD @@RA-@ Oil-Resistant cable. Number of Wires Emitter: 5, Receiver: 8 Cable Length 0.3 m Cable Diameter 6 mm Minimum Bending Radius R36 mm Cascading cable Type of Connection M12 connectors: 8-pin emitter and receiver. IP67 rated when mated. Number of Wires Emitter: 5, Receiver: 8 Cable Length 0.3 m Cable Diameter 6 mm Minimum Bending Radius R5 mm F39-JD @RA-@ Oil-Resistant cable - Single-Ended Cable Type of Connection M12 connectors: 8-pin emitter and receiver. Cables prewired to the sensors. IP67 and IP67G (JIS C 0920 Annex 1)* rated when mated. * F3SG-RR meets the degree of protection when it is correctly connected with the power cable. The degree of protection is not satisfied with the part where cable wires are uncovered. Number of Wires Emitter: 5, Receiver: 8 Cable Length Refer to page 46. Cable Diameter 6 mm Minimum Bending Radius R36 mm Extension cable - Single-Ended Cable (F39-JD @A) - Double-Ended Cable (F39-JD @B) Type of Connection M12 connectors: 8-pin emitter and receiver. IP67 rated when mated. Number of Wires Emitter: 8, Receiver: 8 Cable Length Refer to page 46 and 47. Cable Diameter 6.6 mm Minimum Bending Radius R36 mm Extension of Power Cable 100 m max. (Emitter/Receiver) Material Material Housing: Aluminum alloy Cap: PBT resin Front window: Acrylic resin Cable: Fluororesin FE plate: Stainless steel Weight Refer to page 52 . Included Accessories Safety Precautions, Quick Installation Manual, Troubleshooting Guide Sticker, Warning Zone Label, End Cap (for switching External Test Input function) Conformity Conforming standards Refer to page 53. Performance Level (PL)/Safety category PL e/Category 4 (EN ISO 13849-1:2015) PFHD 1.1 × 10-8 (IEC 61508) Proof test interval TM Every 20 years (IEC 61508) SFF 99% (IEC 61508) HFT 1 (IEC 61508) Classification Type B (IEC 61508-2) Communication System Bluetooth Version 3.0 Communication Profile SPP (Serial Port Profile) Transmission Distance Approx. 10 m max. (Output power: Class 2) * F3SG-4RR-14 F3SG-4RR-25 |
|
