F3SG-R datasheet(42/164 Pages) OMRON

42 / 164 page

F3SG-RA

Cascading Cable for Emitter (F39-JGR2W-L, sold separately)

Cascading Cable for Receiver (F39-JGR2W-D, sold separately)

Y-Joint Plug/Socket Connector (F39-GCNY2, sold separately)

Interface Unit (F39-GIF, sold separately)

200

40.7

23.4

Insulated vinyl round cable dia. 6 mm, 5-wire

(Cross section of conductor: 0.15 mm2/Insulator diameter: dia. 1 mm)

Connector

M12 IP67 Connector 5-pin

M2.5 screw

200

40.7

23.4

Insulated vinyl round cable dia. 6 mm, 8-wire

(Cross section of conductor: 0.15 mm2/Insulator diameter: dia. 1 mm)

Connector

M12 IP67 Connector 8-pin

M2.5 screw

Plug marked with

(bule circle): Connect to control panel side

Socket marked with

(white circle): Connect to emitter

CN1

CN2

17.7

45.5

500

40.7

15.0

M12 x 1

4.6

dia.

To control

panel side

To emitter

M12 IP67 connector, 8-wire

M12 IP67 connector, 5-wire

M12 IP67 connector, 8-wire

Insulated vinyl round cable dia. 6

To receiver

Material: PBT (Main body)

67.9

35.8

(16)

(12)

(625.7)

(46)

Insulated vinyl round cable 4.6 dia. Standard length: 0.5 m

(11.8)

300

54.4

23.3

17.5 dia.

4.6 dia.

5.4 dia.

2,000

14.5

17.5 dia.

7.7
