F3SG-RA

Indicator

Emitter

Receiver

* The LED is illuminated when the EDM input is in ON state regardless of wiring with EDM used or unused.

Interface Unit

Lamp

Name of Indicator

Color

Illuminated

Blinking

Test

TEST

Green

−

External Test is being performed

Operating range

LONG

Green

Long range mode is selected

Lockout state due to DIP Switch setting error

or Operating range selection setting error

Power

POWER

Green

Power is ON.

Error due to noise

Lockout

LOCKOUT

Red

−

Lockout state due to error in emitter

Name of Indicator

Color

Illuminated

Blinking

Top-beam-state

TOP

Blue

The top beam is unblocked

Muting/Override state, or Lockout state due to Cap

error or Other sensor error

PNP/NPN mode

NPN

Green

NPN mode is selected by DIP Switch

−

Response time

SLOW

Green

Response Time Adjustment is enabled

−

Sequence error

SEQ

Yellow

−

Sequence error in Muting or Pre-reset mode

Blanking

BLANK

Green

Blanking, Warning Zone or Reduced Resolution is

enabled

Teach-in mode, or Blanking Monitoring error

Configuration

CFG

Green

−

Teach-in mode, zone measurement beng performed

by Dynamic Muting, or Lockout state due to

Parameter error or Cascading Configuration error

Interlock

INT-LK

Yellow

Interlock state

Pre-reset mode

External device

monitoring

EDM

Green

RESET input is in ON state *

Lockout state due to EDM error

Internal error

INTERNAL

Red

−

Lockout state due to Internal error, or error due

to abnormal power supply or noise

Lockout

LOCKOUT

Red

−

Lockout state due to error in receiver

Stable-state

STB

Green

Incident light level is 170% or higher of ON-threshold

Safety output is instantaneously turned OFF due to

ambient light or vibration

ON/OFF

Green

Safety output is in ON state

−

Red

Safety output is in OFF state, or the sensor is in

Setting state

Lockout state due to Safety Output error, or error due

to abnormal power supply or noise

Communication

COM

Green

Synchronization between emitter and receiver is

maintained

Lockout state due to Communication error, or error

due to abnormal power supply or noise

Bottom-beam-state

BTM

Blue

The bottom beam is unblocked

Muting/Override state, or Lockout state due to DIP

Switch setting error

Main unit

PC/AT compatible machine (computer that runs Microsoft Windows)

Operating system (OS)

Windows 7 (32-bit/64-bit), Windows 8, 8.1 (32-bit/64-bit), Windows 10 (32-bit/64-bit)

Communication port

USB port

×1

Ambient temperature

Operating: -10 to 55

°C, Storage: -30 to 70°C (non-icing and non-condensing)

Ambient humidity

Operating: 35% to 85%, Storage: 35% to 95% (non-condensing)

Item

F39-LP

Applicable Sensor

F3SG-

@RA/RR Series Safety Light Curtain (Receiver)

LED Light Color

Red/Orange/Green

Power Supply Voltage

24 VDC

±20%, ripple p-p 10% max. (shares sensor′s power supply)

Current Consumption

25 mA max. (shares sensor

′s power supply.)

Ambient Temperature

Operating: -10 to 55

°C, Storage: -25 to 70°C

Ambient Humidity

Operating: 35% to 85%, Storage: 35% to 95%

Vibration Resistance

10 to 55 Hz, Multiple amplitude of 0.7 mm,20 sweeps for all 3 axes

Shock Resistance

100 m/s2 , 1000 shocks for all 3 axes

Degree of Protection

IP65 and IP67 (When attached to F3SG)

Type of Connection

Connectable to F3SG-RA

′s terminal connector

Material

Lighting element: PC, Other body parts: PBT

Weight

45 g (when packaged)
