65 / 164 page

F3SG-RR

Mounted with Top/Bottom Brackets (F39-LGRTB-2) and Intermediate Bracket (F39-LGRA)

Backside Mounting

* The number of brackets required to mount either one of emitter and receiver.

Dimension C

4-digit number of the type name (Protective height)

Dimension D

C-20

Dimension G

C+51+N1+N2

Dimension H

C+54+N1+N2

Dimension I

C+88+N1+N2

Dimension J

C+106+N1+N2

Dimension N1

0 to 30

Dimension N2

0 to 13

Dimension P

F3SG-4RR

@@@@-14

F3SG-4RR

@@@@-25

Protective

height (C)

Number of Top/

Bottom Brackets *

Number of

Intermediate

Brackets *

Dimension F

0240 to 1040

−

1120 to 1920

1000 mm max.

46.35

31.4

5.5

6.5

3.95

2-M4

9 dia.

4-M5

2-M8

2-M6

2-M4

(F39-LGRTB-2)

(F39-LGRA)

(F39-LGRTB-2)

26.3

3.95

<Screw for Top/Bottom

Bracket: M5>

<Screw for Top/Bottom

Bracket: M6 or M8>

Intermediate Bracket

Top/Bottom Bracket

Backside:2-M4

2-M5 or M6
