103 / 164 page  F3SG-RA-01TS 103 Indicator Emitter Receiver * The LED is illuminated when the EDM input is in ON state regardless of wiring with EDM used or unused. Interface Unit Lamp Name of Indicator Color Illuminated Blinking TEST Green − External Test is being performed LONG Green Long range mode is selected Lockout state due to DIP Switch setting error or Operating range selection setting error POWER Green Power is ON. Error due to noise LOCKOUT Red − Lockout state due to error in emitter Name of Indicator Color Illuminated Blinking TOP Blue The top beam is unblocked Lockout state due to Cap error or Other sensor error NPN Green NPN mode is selected by DIP Switch − CFG Green − Lockout state due to Cascading Configuration error EDM Green EDM input is in ON state * Lockout state due to EDM error INTERNAL Red − Lockout state due to Internal error, or error due to abnormal power supply or noise LOCKOUT Red − Lockout state due to error in receiver STB Green Incident light level is 170% or higher of ON-threshold Safety output is instantaneously turned OFF due to ambient light or vibration ON/OFF Green Safety output is in ON state − Red Safety output is in OFF state Lockout state due to Safety Output error, or error due to abnormal power supply or noise COM Green Synchronization between emitter and receiver is maintained Lockout state due to Communication error, or error due to abnormal power supply or noise BTM Blue The bottom beam is unblocked Lockout state due to DIP Switch setting error Main unit PC/AT compatible machine (computer that runs Microsoft Windows) Operating system (OS) Windows 7 (32-bit/64-bit), Windows 8, 8.1 (32-bit/64-bit), Windows 10 (32-bit/64-bit) Communication port USB port ×1 Ambient temperature Operating: -10 to 55 °C, Storage: -30 to 70°C(non-icing and non-condensing) Ambient humidity Operating: 35% to 85%, Storage: 35% to 95%(non-condensing) Item F39-LP Applicable Sensor F3SG- @RA Series Safety Light Curtain (Receiver) LED Light Color Red/Orange/Green Power Supply Voltage 24 VDC ±20%, ripple p-p 10% max.(shares sensor′s power supply) Current Consumption 25 mA max. (shares sensor ′s power supply.) Ambient Temperature Operating: -10 to 55 °C, Storage: -25 to 70°C Ambient Humidity Operating: 35% to 85%, Storage: 35% to 95% Vibration Resistance 10 to 55 Hz, Multiple amplitude of 0.7 mm,20 sweeps for all 3 axes Shock Resistance 100 m/s2 , 1000 shocks for all 3 axes Degree of Protection IP65 and IP67(When attached to F3SG) Type of Connection Connectable to F3SG-RA ′s terminal connector Material Lighting element: PC, Other body parts: PBT Weight 45 g (when packaged) |
|
