F3W-MA

151

Ratings/Specifications

*1. The net weight is the weight of an emitter and a receiver.

*2. The gross weight is the weight of an emitter, a receiver, included accessories and a package.

F3W-MA0100P

F3W-MA0300P

Perfor-

mance

Beam Gap between Muting Trigger

Beams

100 mm

300 mm

Number of Beams

820

Standard Detection Object

30 mm

Operating

Range

Long

0.3 to 20.0 m (1 to 65 ft.)

Short

0.3 to 7.0 m (1 to 23 ft.)

Response Time

Operation

13 ms max.

Reset

26 ms max. (Synchronized)

78 ms max. (Not synchronized)

Effective Aperture Angle

±2.5° max., emitter and receiver at operating range of 3 m or greater

Light Source

Infrared LEDs, Wavelength: 870 nm

Startup Waiting Time

2 s max.

Electrical

Power Supply Voltage (Vs)

SELV/PELV 24 VDC

±20% (ripple p-p 10% max.)

Current

Consumption

Emitter

35 mA

45 mA

Receiver

75 mA

Muting Outputs

Two PNP transistor outputs. *

Load current of 300 mA max.,

Residual voltage of 2 V max. (except for voltage drop due to cable extension)j

* This product is a PNP output model. Use with the PNP output model safety light curtain.

Output Opera-

tion Mode

Muting Output A

Dark-ON

(Muting Output A is enabled when MuteA trigger beam is blocked.)

Muting Output B

Dark-ON

(Muting Output B is enabled when MuteB trigger beam is blocked.)

Input Voltage

ON Voltage

[MuteEnable]

Vs to Vs-3 V (sink current 5 mA max.) *

OFF Voltage

[Mute Enable]

0 to 1/2 Vs, or open *

* The Vs indicates a supply voltage value in your environment.

Indicators

Refer to page 152. LED Indicator Status

Protective Circuit

Protective Circuit Output short protection, Power supply reverse polarity protection

Insulation Resistance

20 M

Ω or higher (500 VDC megger)

Dielectric Strength

1,000 VAC, 50/60 Hz (1 min)

Functional Functions

- Scan Code Selection

- Operation Mode Selection (Point to Point Detection/ Chattering and Void Space

Prevention)

- Off-Delay

- Muting Enable

- Muting Trigger Beam Allocation

- Operating Range Selection

Environ-

mental

Ambient

Temperature

Operating

-10 to 55

°C (13 to 131°F) (non-icing)

Storage

-25 to 70

°C (-13 to 158°F)

Ambient

Humidity

Operating

35% to 85% (non-condensing)

Storage

35% to 95%

Ambient Illuminance

Incandescent lamp: 3,000 Ix max. on receiver surface

Sunlight: 10,000 Ix max. on receiver surface

Degree of Protection (IEC 60529)

IP65 and IP67

Vibration Resistance (IEC 61496-1)

10 to 55 Hz, Multiple amplitude of 0.7 mm, 20 sweeps for all 3 axes

Shock Resistance (IEC 61496-1)

100 m/s2, 1000 shocks for all 3 axes

Pollution Degree (IEC 60664-1)

Pollution Degree 3

Connec-

tions

Power Cable

Type of Connection M12 connectors: 5-pin emitter, 8-pin receiver, IP67 rated when mated, Cables prewired to sensors

Number of Wires

Emitter: 5, Receiver: 8

Cable Length

0.3 mm

Cable Diameter

6 mm

Minimum Bending

Radius

R5 mm

Extension of Power Cable

100 m max.

Note: For T-Shaped configuration with COM lines, the length of cable extension is 30m max.

Material

Housing: Aluminum alloy, Cap: PBT resin, Front window: Acrylic resin, Cable: Oil-resistant PVC resin,

FE plate: Stainless steel

Net Weight *1

0.7 kg

0.9 kg

Gross Weight *2

1.3 kg

2.2 kg

Included Accessories

Instruction Sheet
