F3W-MA

152

LED Indicator Status

Shown below are indication statuses of F3W-MA LED indicators when you purchased.

Emitter

Receiver

Name of Indicator

Color

Illuminated

Blinking

Operating range

LONG

Green

Long Range mode is selected by DIP Switch.

Running

RUN

Green

Power is ON.

Error

ERR

Red

Error in emitter. Generic error happens.

Name of Indicator

Color

Illuminated

Blinking

Top-beam-state

TOP

Blue

The top beam is unblocked.

Muting output A

MUTE A

Green

Muting Output A is activated.

Muting output B

MUTE B

Green

Muting Output B is activated.

Off-Delay

DELAY

Yellow

Off-Delay function is enabled by DIP Switch.

Chattering/ Void

space

CHAT

Green

Chattering and Void Space Prevention mode is se-

lected by DIP Switch.

Muting Enable

MUTE

DISABLE

Red

The Muting Enable function is enabled and Muting

Enable input is turned OFF by DIP Switch.

Error

ERR

Red

Error in receiver. Generic error happens.

Stable-state

STB

Green

Incident light level is 170% or higher of ON-threshold

Running

RUN

Green

Power is ON.

Communication

COM

Green

Synchronization between emitter and receiver is

maintained.

[Primary sensor]

- Start-up (for approx. 3 s)

- Synchronization between emitter

and receiver is lost

Bottom-beamstate

BTM

Blue

The bottom beam is unblocked.
